| Size (DN) | A (mm) | B (mm) | C (mm) | Order No |
|---|---|---|---|---|
| 16 | 7.5 | 34 | 4.4 | VC4FLF1SS016 |
| 25 | 12 | 54 | 6.8 | VC4FLF1SS025 |
| 40 | 13 | 69.9 | 6.8 | VC4FLF1SS040 |
| 50 | 16.5 | 85.7 | 8.4 | VC4FLF1SS050 |
| 63 | 17.5 | 113.5 | 8.4 | VC4FLF1SS063 |
| 75 | 18 | 117.4 | 8.4 | VC4FLF1SS075 |
| 100 | 20 | 152 | 8.4 | VC4FLF1SS100 |
| 125 | 21.5 | 171.4 | 8.4 | VC4FLF1SS125 |
| 160 | 21.5 | 202.4 | 8.4 | VC4FLF1SS160 |
| 200 | 24.5 | 253.2 | 8.4 | VC4FLF1SS200 |
| 250 | 24.5 | 304.8 | 8.4 | VC4FLF1SS250 |
| 300 | 28.5 | 355.6 | 10.8 | VC4FLF1SS300 |
| 350 | 28.5 | 419.1 | 10.8 | VC4FLF1SS350 |
| Size (DN) | A (mm) | B (mm) | C (mm) | Order No |
|---|---|---|---|---|
| 16 | 7.5 | 34 | 4.4 | VC4FLF2SS016 |
| 25 | 12 | 54 | 6.8 | VC4FLF2SS025 |
| 40 | 13 | 69.9 | 6.8 | VC4FLF2SS040 |
| 50 | 16.5 | 85.7 | 8.4 | VC4FLF2SS050 |
| 63 | 17.5 | 113.5 | 8.4 | VC4FLF2SS063 |
| 75 | 18 | 117.4 | 8.4 | VC4FLF2SS075 |
| 100 | 20 | 152 | 8.4 | VC4FLF2SS100 |
| 125 | 21.5 | 171.4 | 8.4 | VC4FLF2SS125 |
| 160 | 21.5 | 202.4 | 8.4 | VC4FLF2SS160 |
| 200 | 24.5 | 253.2 | 8.4 | VC4FLF2SS200 |
| 250 | 24.5 | 304.8 | 8.4 | VC4FLF2SS250 |
| 300 | 28.5 | 355.6 | 10.8 | VC4FLF2SS300 |
| 350 | 28.5 | 419.1 | 10.8 | VC4FLF2SS350 |
| Size (DN) | A (mm) | B (mm) | C (mm) | Order No |
|---|---|---|---|---|
| 16 | 7.5 | 34 | 4.4 | VC4FLF3SS016 |
| 25 | 12 | 54 | 6.8 | VC4FLF3SS025 |
| 40 | 13 | 69.9 | 6.8 | VC4FLF3SS040 |
| 50 | 16.5 | 85.7 | 8.4 | VC4FLF3SS050 |
| 63 | 17.5 | 113.5 | 8.4 | VC4FLF3SS063 |
| 75 | 18 | 117.4 | 8.4 | VC4FLF3SS075 |
| 100 | 20 | 152 | 8.4 | VC4FLF3SS100 |
| 125 | 21.5 | 171.4 | 8.4 | VC4FLF3SS125 |
| 160 | 21.5 | 202.4 | 8.4 | VC4FLF3SS160 |
| 200 | 24.5 | 253.2 | 8.4 | VC4FLF3SS200 |
| 250 | 24.5 | 304.8 | 8.4 | VC4FLF3SS250 |
| 300 | 28.5 | 355.6 | 10.8 | VC4FLF3SS300 |
| 350 | 28.5 | 419.1 | 10.8 | VC4FLF3SS350 |
