Request a quotation from Anadolu Vacuum for standard vacuum components, custom-engineered parts, UHV chambers, flanges, fittings, and complete vacuum solutions. Share your technical requirements, drawings, quantities, or project details, and our team will evaluate your request with precision, speed, and engineering-focused support.
| Size (DN) | A (mm) | B (mm) | J (mm) | O-ring material | Order No |
|---|---|---|---|---|---|
| 10 | 12 | 10 | 15 | FKM | VC1SLB1AL010-FKM |
| 10 | 12 | 10 | 15 | CR | VC1SLB1AL010-CR |
| 10 | 12 | 10 | 15 | NBR | VC1SLB1AL010-NBR |
| 10 | 12 | 10 | 15 | EPDM | VC1SLB1AL010-EPDM |
| 10 | 12 | 10 | 15 | VMQ (SILICON) | VC1SLB1AL010-VMQ |
| 16 | 17 | 16 | 18 | FKM | VC1SLB1AL016-FKM |
| 16 | 17 | 16 | 18 | CR | VC1SLB1AL016-CR |
| 16 | 17 | 16 | 18 | NBR | VC1SLB1AL016-NBR |
| 16 | 17 | 16 | 18 | EPDM | VC1SLB1AL016-EPDM |
| 16 | 17 | 16 | 18 | VMQ (SILICON) | VC1SLB1AL016-VMQ |
| 20 | 22 | 20 | 24 | FKM | VC1SLB1AL020-FKM |
| 20 | 22 | 20 | 25 | CR | VC1SLB1AL020-CR |
| 20 | 22 | 20 | 25 | NBR | VC1SLB1AL020-NBR |
| 20 | 22 | 20 | 25 | EPDM | VC1SLB1AL020-EPDM |
| 20 | 22 | 20 | 25 | VMQ (SILICON) | VC1SLB1AL020-VMQ |
| 25 | 26 | 24 | 28 | FKM | VC1SLB1AL025-FKM |
| 25 | 26 | 24 | 28 | CR | VC1SLB1AL025-CR |
| 25 | 26 | 24 | 28 | NBR | VC1SLB1AL025-NBR |
| 25 | 26 | 24 | 28 | EPDM | VC1SLB1AL025-EPDM |
| 25 | 26 | 24 | 28 | VMQ (SILICON) | VC1SLB1AL025-VMQ |
| 32 | 34 | 32 | 35 | FKM | VC1SLB1AL032-FKM |
| 32 | 34 | 32 | 35 | CR | VC1SLB1AL032-CR |
| 32 | 34 | 32 | 35 | NBR | VC1SLB1AL032-NBR |
| 32 | 34 | 32 | 35 | EPDM | VC1SLB1AL032-EPDM |
| 32 | 34 | 32 | 35 | VMQ (SILICON) | VC1SLB1AL032-VMQ |
| 40 | 41 | 40 | 42 | FKM | VC1SLB1AL040-FKM |
| 40 | 41 | 40 | 42 | CR | VC1SLB1AL040-CR |
| 40 | 41 | 40 | 42 | NBR | VC1SLB1AL040-NBR |
| 40 | 41 | 40 | 42 | EPDM | VC1SLB1AL040-EPDM |
| 40 | 41 | 40 | 42 | VMQ (SILICON) | VC1SLB1AL040-VMQ |
| 50 | 52 | 50 | 55 | FKM | VC1SLB1AL050-FKM |
| 50 | 52 | 50 | 55 | CR | VC1SLB1AL050-CR |
| 50 | 52 | 50 | 55 | NBR | VC1SLB1AL050-NBR |
| 50 | 52 | 50 | 55 | EPDM | VC1SLB1AL050-EPDM |
| 50 | 52 | 50 | 55 | VMQ (SILICON) | VC1SLB1AL050-VMQ |
| Size (DN) | A (mm) | B (mm) | J (mm) | O-ring material | Order No |
|---|---|---|---|---|---|
| 10 | 12 | 10 | 15 | FKM | VC1SLB1PL010-FKM |
| 16 | 17 | 16 | 18 | FKM | VC1SLB1PL016-FKM |
| 20 | 22 | 20 | 24 | FKM | VC1SLB1PL020-FKM |
| 25 | 26 | 24 | 28 | FKM | VC1SLB1PL025-FKM |
| 32 | 34 | 32 | 35 | FKM | VC1SLB1PL032-FKM |
| 40 | 41 | 40 | 42 | FKM | VC1SLB1PL040-FKM |
| 50 | 52 | 50 | 55 | FKM | VC1SLB1PL050-FKM |
| Size (DN) | A (mm) | B (mm) | J (mm) | O-ring material | Order No |
|---|---|---|---|---|---|
| 10 | 12 | 10 | 15 | FKM | VC1SLB1SS010-FKM |
| 10 | 12 | 10 | 15 | CR | VC1SLB1SS010-CR |
| 10 | 12 | 10 | 15 | NBR | VC1SLB1SS010-NBR |
| 10 | 12 | 10 | 15 | EPDM | VC1SLB1SS010-EPDM |
| 10 | 12 | 10 | 15 | VMQ (SILICON) | VC1SLB1SS010-VMQ |
| 16 | 17 | 16 | 18 | FKM | VC1SLB1SS016-FKM |
| 16 | 17 | 16 | 18 | CR | VC1SLB1SS016-CR |
| 16 | 17 | 16 | 18 | NBR | VC1SLB1SS016-NBR |
| 16 | 17 | 16 | 18 | EPDM | VC1SLB1SS016-EPDM |
| 16 | 17 | 16 | 18 | VMQ (SILICON) | VC1SLB1SS016-VMQ |
| 20 | 22 | 20 | 24 | FKM | VC1SLB1SS020-FKM |
| 20 | 22 | 20 | 25 | CR | VC1SLB1SS020-CR |
| 20 | 22 | 20 | 25 | NBR | VC1SLB1SS020-NBR |
| 20 | 22 | 20 | 25 | EPDM | VC1SLB1SS020-EPDM |
| 20 | 22 | 20 | 25 | VMQ (SILICON) | VC1SLB1SS020-VMQ |
| 25 | 26 | 24 | 28 | FKM | VC1SLB1SS025-FKM |
| 25 | 26 | 24 | 28 | CR | VC1SLB1SS025-CR |
| 25 | 26 | 24 | 28 | NBR | VC1SLB1SS025-NBR |
| 25 | 26 | 24 | 28 | EPDM | VC1SLB1SS025-EPDM |
| 25 | 26 | 24 | 28 | VMQ (SILICON) | VC1SLB1SS025-VMQ |
| 32 | 34 | 32 | 35 | FKM | VC1SLB1SS032-FKM |
| 32 | 34 | 32 | 35 | CR | VC1SLB1SS032-CR |
| 32 | 34 | 32 | 35 | NBR | VC1SLB1SS032-NBR |
| 32 | 34 | 32 | 35 | EPDM | VC1SLB1SS032-EPDM |
| 32 | 34 | 32 | 35 | VMQ (SILICON) | VC1SLB1SS032-VMQ |
| 40 | 41 | 40 | 42 | FKM | VC1SLB1SS040-FKM |
| 40 | 41 | 40 | 42 | CR | VC1SLB1SS040-CR |
| 40 | 41 | 40 | 42 | NBR | VC1SLB1SS040-NBR |
| 40 | 41 | 40 | 42 | EPDM | VC1SLB1SS040-EPDM |
| 40 | 41 | 40 | 42 | VMQ (SILICON) | VC1SLB1SS040-VMQ |
| 50 | 52 | 50 | 55 | FKM | VC1SLB1SS050-FKM |
| 50 | 52 | 50 | 55 | CR | VC1SLB1SS050-CR |
| 50 | 52 | 50 | 55 | NBR | VC1SLB1SS050-NBR |
| 50 | 52 | 50 | 55 | EPDM | VC1SLB1SS050-EPDM |
| 50 | 52 | 50 | 55 | VMQ (SILICON) | VC1SLB1SS050-VMQ |
| Size (DN) | A (mm) | B (mm) | J (mm) | O-ring material | Order No |
|---|---|---|---|---|---|
| 10 | 12 | 10 | 15 | FKM | VC1SLB2SS010-FKM |
| 10 | 12 | 10 | 15 | CR | VC1SLB2SS010-CR |
| 10 | 12 | 10 | 15 | NBR | VC1SLB2SS010-NBR |
| 10 | 12 | 10 | 15 | EPDM | VC1SLB2SS010-EPDM |
| 10 | 12 | 10 | 15 | VMQ (SILICON) | VC1SLB2SS010-VMQ |
| 16 | 17 | 16 | 18 | FKM | VC1SLB2SS016-FKM |
| 16 | 17 | 16 | 18 | CR | VC1SLB2SS016-CR |
| 16 | 17 | 16 | 18 | NBR | VC1SLB2SS016-NBR |
| 16 | 17 | 16 | 18 | EPDM | VC1SLB2SS016-EPDM |
| 16 | 17 | 16 | 18 | VMQ (SILICON) | VC1SLB2SS016-VMQ |
| 20 | 22 | 20 | 24 | FKM | VC1SLB2SS020-FKM |
| 20 | 22 | 20 | 25 | CR | VC1SLB2SS020-CR |
| 20 | 22 | 20 | 25 | NBR | VC1SLB2SS020-NBR |
| 20 | 22 | 20 | 25 | EPDM | VC1SLB2SS020-EPDM |
| 20 | 22 | 20 | 25 | VMQ (SILICON) | VC1SLB2SS020-VMQ |
| 25 | 26 | 24 | 28 | FKM | VC1SLB2SS025-FKM |
| 25 | 26 | 24 | 28 | CR | VC1SLB2SS025-CR |
| 25 | 26 | 24 | 28 | NBR | VC1SLB2SS025-NBR |
| 25 | 26 | 24 | 28 | EPDM | VC1SLB2SS025-EPDM |
| 25 | 26 | 24 | 28 | VMQ (SILICON) | VC1SLB2SS025-VMQ |
| 32 | 34 | 32 | 35 | FKM | VC1SLB2SS032-FKM |
| 32 | 34 | 32 | 35 | CR | VC1SLB2SS032-CR |
| 32 | 34 | 32 | 35 | NBR | VC1SLB2SS032-NBR |
| 32 | 34 | 32 | 35 | EPDM | VC1SLB2SS032-EPDM |
| 32 | 34 | 32 | 35 | VMQ (SILICON) | VC1SLB2SS032-VMQ |
| 40 | 41 | 40 | 42 | FKM | VC1SLB2SS040-FKM |
| 40 | 41 | 40 | 42 | CR | VC1SLB2SS040-CR |
| 40 | 41 | 40 | 42 | NBR | VC1SLB2SS040-NBR |
| 40 | 41 | 40 | 42 | EPDM | VC1SLB2SS040-EPDM |
| 40 | 41 | 40 | 42 | VMQ (SILICON) | VC1SLB2SS040-VMQ |
| 50 | 52 | 50 | 55 | FKM | VC1SLB2SS050-FKM |
| 50 | 52 | 50 | 55 | CR | VC1SLB2SS050-CR |
| 50 | 52 | 50 | 55 | NBR | VC1SLB2SS050-NBR |
| 50 | 52 | 50 | 55 | EPDM | VC1SLB2SS050-EPDM |
| 50 | 52 | 50 | 55 | VMQ (SILICON) | VC1SLB2SS050-VMQ |
