| Size (DN) | Reducer Flange Size (DN) | A (mm) | B (mm) | C | D (mm) | Order No |
|---|---|---|---|---|---|---|
| 40 | 16 | 13 | 16 | M4 | 6 | VC4FLO1SS040-016 |
| 63 | 16 | 17.5 | 16 | M4 | 6 | VC4FLO1SS063-016 |
| 63 | 40 | 17.5 | 37 | M6 | 9 | VC4FLO1SS063-040 |
| 100 | 40 | 20 | 37 | M6 | 9 | VC4FLO1SS100-040 |
| 100 | 50 | 20 | 47.5 | M8 | 10 | VC4FLO1SS100-050 |
| 100 | 63 | 20 | 66 | M8 | 13 | VC4FLO1SS100-063 |
| 160 | 40 | 21.5 | 37 | M6 | 9 | VC4FLO1SS160-040 |
| 160 | 63 | 21.5 | 66 | M8 | 13 | VC4FLO1SS160-063 |
| 160 | 100 | 21.5 | 100 | M8 | 13 | VC4FLO1SS160-100 |
| 200 | 40 | 24.5 | 37 | M6 | 9 | VC4FLO1SS200-040 |
| 200 | 63 | 24.5 | 66 | M8 | 13 | VC4FLO1SS200-063 |
| 200 | 100 | 24.5 | 100 | M8 | 13 | VC4FLO1SS200-100 |
| 200 | 160 | 24.5 | 155 | M8 | 13 | VC4FLO1SS200-160 |
| 250 | 40 | 26 | 37 | M6 | 9 | VC4FLO1SS250-040 |
| 250 | 63 | 26 | 66 | M8 | 13 | VC4FLO1SS250-063 |
| 250 | 100 | 26 | 100 | M8 | 13 | VC4FLO1SS250-100 |
| 250 | 160 | 26 | 155 | M8 | 13 | VC4FLO1SS250-160 |
| 250 | 200 | 26 | 200 | M8 | 13 | VC4FLO1SS250-200 |
| Size (DN) | Reducer Flange Size (DN) | A (mm) | B (mm) | C | D (mm) | Order No |
|---|---|---|---|---|---|---|
| 40 | 16 | 13 | 16 | M4 | 6 | VC4FLO2SS040-016 |
| 63 | 16 | 17.5 | 16 | M4 | 6 | VC4FLO2SS063-016 |
| 63 | 40 | 17.5 | 37 | M6 | 9 | VC4FLO2SS063-040 |
| 100 | 40 | 20 | 37 | M6 | 9 | VC4FLO2SS100-040 |
| 100 | 50 | 20 | 47.5 | M8 | 10 | VC4FLO1SS100-050 |
| 100 | 63 | 20 | 66 | M8 | 13 | VC4FLO2SS100-063 |
| 160 | 40 | 21.5 | 37 | M6 | 9 | VC4FLO2SS160-040 |
| 160 | 63 | 21.5 | 66 | M8 | 13 | VC4FLO2SS160-063 |
| 160 | 100 | 21.5 | 100 | M8 | 13 | VC4FLO2SS160-100 |
| 200 | 40 | 24.5 | 37 | M6 | 9 | VC4FLO2SS200-040 |
| 200 | 63 | 24.5 | 66 | M8 | 13 | VC4FLO2SS200-063 |
| 200 | 100 | 24.5 | 100 | M8 | 13 | VC4FLO2SS200-100 |
| 200 | 160 | 24.5 | 155 | M8 | 13 | VC4FLO2SS200-160 |
| 250 | 40 | 26 | 37 | M6 | 9 | VC4FLO2SS250-040 |
| 250 | 63 | 26 | 66 | M8 | 13 | VC4FLO2SS250-063 |
| 250 | 100 | 26 | 100 | M8 | 13 | VC4FLO2SS250-100 |
| 250 | 160 | 26 | 155 | M8 | 13 | VC4FLO2SS250-160 |
| 250 | 200 | 26 | 200 | M8 | 13 | VC4FLO2SS250-200 |
| Size (DN) | Reducer Flange Size (DN) | A (mm) | B (mm) | C | D (mm) | Order No |
|---|---|---|---|---|---|---|
| 40 | 16 | 13 | 16 | M4 | 6 | VC4FLO1SS040-016 |
| 63 | 16 | 17.5 | 16 | M4 | 6 | VC4FLO1SS063-016 |
| 63 | 40 | 17.5 | 37 | M6 | 9 | VC4FLO1SS063-040 |
| 100 | 40 | 20 | 37 | M6 | 9 | VC4FLO1SS100-040 |
| 100 | 50 | 20 | 47.5 | M8 | 10 | VC4FLO1SS100-050 |
| 100 | 63 | 20 | 66 | M8 | 13 | VC4FLO1SS100-063 |
| 160 | 40 | 21.5 | 37 | M6 | 9 | VC4FLO1SS160-040 |
| 160 | 63 | 21.5 | 66 | M8 | 13 | VC4FLO1SS160-063 |
| 160 | 100 | 21.5 | 100 | M8 | 13 | VC4FLO1SS160-100 |
| 200 | 40 | 24.5 | 37 | M6 | 9 | VC4FLO1SS200-040 |
| 200 | 63 | 24.5 | 66 | M8 | 13 | VC4FLO1SS200-063 |
| 200 | 100 | 24.5 | 100 | M8 | 13 | VC4FLO1SS200-100 |
| 200 | 160 | 24.5 | 155 | M8 | 13 | VC4FLO1SS200-160 |
| 250 | 40 | 26 | 37 | M6 | 9 | VC4FLO1SS250-040 |
| 250 | 63 | 26 | 66 | M8 | 13 | VC4FLO1SS250-063 |
| 250 | 100 | 26 | 100 | M8 | 13 | VC4FLO1SS250-100 |
| 250 | 160 | 26 | 155 | M8 | 13 | VC4FLO1SS250-160 |
| 250 | 200 | 26 | 200 | M8 | 13 | VC4FLO1SS250-200 |
