ISO-KF Edge Seal One-Side Inner Centered
ISO-KF Edge Seal One-Side Inner Centered - Image 2

ISO-KF Edge Seal One-Side Inner Centered

Categories ,

Description

The ISO-KF Edge Seal One-Side Inner Centered is designed for vacuum systems that require a metal sealing solution with inner centering and one-side edge geometry. The catalog states that it offers no gas permeation, is suitable for cryo, radiation tolerant, and nuclear applications, is clean room application compatible, and is intended for stainless steel flanges. It is used with an ISO-KF clamp for metal seals and is specified for single use only. The product is available in Aluminium EN AW-1050 and Copper versions.

Request a Quote
Field Data
Product Name ISO-KF Edge Seal One-Side Inner Centered
System ISO-KF
Product Type Edge Seal One-Side Inner Centered
Sealing Type Metal seal
Centering Type Inner centered
Gas Permeation No gas permeation
Application Notes Cryo, radiation tolerant and nuclear application
Clean Room Compatibility Clean room application compatible
Flange Compatibility For stainless steel flanges
Fastener ISO-KF Clamp for metal seals
Reusability For single use only
Material Versions Aluminium EN AW-1050, Copper
Available Sizes (DN) 10, 16, 20, 25, 32, 40, 50
Main Dimensions A, B, J
Temperature Range - Aluminium EN AW-1050 -196 to 150 °C
Temperature Range - Copper -196 to 200 °C
Aluminium EN AW-1050
Size (DN) A (mm) B (mm) J (mm) Order No
10 12 10 18 VC1SLI2AL010
16 17 15 21 VC1SLI2AL016
20 22 20 27 VC1SLI2AL020
25 26 24 30 VC1SLI2AL025
32 34 32 38 VC1SLI2AL032
40 41 39 47 VC1SLI2AL040
50 52 50 59 VC1SLI2AL050
Copper
Size (DN) A (mm) B (mm) J (mm) Order No
10 12 10 18 VC1SLI1CU010
16 17 15 21 VC1SLI1CU016
20 22 20 27 VC1SLI1CU020
25 26 24 30 VC1SLI1CU025
32 34 32 38 VC1SLI1CU032
40 41 39 47 VC1SLI1CU040
50 52 50 59 VC1SLI1CU050

Aluminium EN AW-1050
Size (DN) A (mm) B (mm) J (mm)
10 12 10 18
16 17 15 21
20 22 20 27
25 26 24 30
32 34 32 38
40 41 39 47
50 52 50 59
Copper
Size (DN) A (mm) B (mm) J (mm)
10 12 10 18
16 17 15 21
20 22 20 27
25 26 24 30
32 34 32 38
40 41 39 47
50 52 50 59
