KF inner centering ring, ISO-KF inner centring ring, KF inner centring ring
ISO-KF Inner Centered Inner Ring - Image 2

ISO-KF Inner Centered Inner Ring

Categories ,

Description

ISO-KF inner centering ring available in aluminium EN AW-6082 T6, stainless steel 304, stainless steel 316L and PTFE. Choose from DN10, DN16, DN20, DN25, DN32, DN40 and DN50, with 28 material and size variants. Compare dimensions and order numbers, then request a quotation for your selected variant.

Request a Quote
Field Data
Product Name ISO-KF Inner Centered Inner Ring
System ISO-KF
Product Type Inner Centering Ring
Available Sizes DN10, DN16, DN20, DN25, DN32, DN40, DN50
Material Options Aluminium EN AW-6082 T6; Stainless Steel 304 / 1.4301; Stainless Steel 316L / 1.4404; PTFE
Temperature Range — Aluminium −196 to +150 °C
Temperature Range — Stainless Steel 304 −196 to +300 °C
Temperature Range — Stainless Steel 316L −196 to +350 °C
Temperature Range — PTFE −15 to +150 °C
Main Dimensions ØA and ØB
Additional Drawing Dimensions 8 mm and 3.9 mm
Available Variants 28
Seal Options Various types of O-ring seals are available

Temperature ranges are the catalog-listed values for the respective ring materials.

Aluminium EN AW-6082 T6
Size (DN) A (mm) B (mm) Order No.
10 12 10 VC1SLM1AL010
16 17 16 VC1SLM1AL016
20 22 20 VC1SLM1AL020
25 26 24 VC1SLM1AL025
32 34 32 VC1SLM1AL032
40 41 40 VC1SLM1AL040
50 52 50 VC1SLM1AL050
Stainless Steel 304 / 1.4301
Size (DN) A (mm) B (mm) Order No.
10 12 10 VC1SLM1SS010
16 17 16 VC1SLM1SS016
20 22 20 VC1SLM1SS020
25 26 24 VC1SLM1SS025
32 34 32 VC1SLM1SS032
40 41 40 VC1SLM1SS040
50 52 50 VC1SLM1SS050
Stainless Steel 316L / 1.4404
Size (DN) A (mm) B (mm) Order No.
10 12 10 VC1SLM2SS010
16 17 16 VC1SLM2SS016
20 22 20 VC1SLM2SS020
25 26 24 VC1SLM2SS025
32 34 32 VC1SLM2SS032
40 41 40 VC1SLM2SS040
50 52 50 VC1SLM2SS050
PTFE
Size (DN) A (mm) B (mm) Order No.
10 12 10 VC1SLM1PL010
16 17 16 VC1SLM1PL016
20 22 20 VC1SLM1PL020
25 26 24 VC1SLM1PL025
32 34 32 VC1SLM1PL032
40 41 40 VC1SLM1PL040
50 52 50 VC1SLM1PL050

Aluminium EN AW-6082 T6
Size (DN) A (mm) B (mm)
10 12 10
16 17 16
20 22 20
25 26 24
32 34 32
40 41 40
50 52 50
Stainless Steel 304 / 1.4301
Size (DN) A (mm) B (mm)
10 12 10
16 17 16
20 22 20
25 26 24
32 34 32
40 41 40
50 52 50
Stainless Steel 316L / 1.4404
Size (DN) A (mm) B (mm)
10 12 10
16 17 16
20 22 20
25 26 24
32 34 32
40 41 40
50 52 50
PTFE
Size (DN) A (mm) B (mm)
10 12 10
16 17 16
20 22 20
25 26 24
32 34 32
40 41 40
50 52 50

Download Datasheet from here
