| Product Name |
CF Reducer Tee |
| System |
CF |
| Product Type |
Reducer Tee |
| Configuration |
One fixed and two rotatable flanges (one on each axis) |
| Pressure Range |
1 × 10⁻¹² mbar to ambient pressure |
| Tightness |
≤ 1 × 10⁻¹⁰ mbar l/s |
| Bake-Out Range |
Up to 450 °C |
| Custom Lengths |
Available upon request |
| Tube Surface |
Glass bead blasted |
| Optional Finish |
Polished version on request |
| Material Versions |
Stainless Steel 304 / 1.4301, Stainless Steel 316L / 1.4404 |
| Flange Material |
Same as selected material version |
| Tube Material |
Same as selected material version |
| Available Main Flange Sizes (DN) |
40, 63, 100, 160 |
| Available Reducer Flange Sizes (DN) |
16, 40, 63, 100 |
| Main Dimensions |
A, B |
| Temperature Range - Stainless Steel 304 / 1.4301 |
-196 to 300 °C |
| Temperature Range - Stainless Steel 316L / 1.4404 |
-196 to 350 °C |
