The ISO-KF 90 Elbow (Forging) is designed for ISO-KF vacuum systems that require a compact 90-degree directional change using a forged elbow body. Based on the product sheet image, it is manufactured in Aluminium EN AW-6082 T6 / 3.2315 and has a pressure range of 1 × 10⁻⁸ mbar to 500 mbar over pressure.
| Field | Data |
|---|---|
| Product Name | ISO-KF 90 Elbow (Forging) |
| System | ISO-KF |
| Product Type | 90 Elbow (Forging) |
| Function | 90-degree elbow for ISO-KF vacuum line routing |
| Material Version | Aluminium EN AW-6082 T6 / 3.2315 |
| Pressure Range | 1 × 10⁻⁸ mbar to 500 mbar over pressure |
| Available Sizes (DN) | 10, 16, 25, 40 |
| Main Dimensions | A, B |
| Temperature Range - Aluminium EN AW-6082 T6 / 3.2315 | -196 to 150 °C |
| Size (DN) | A (mm) | B (mm) | Order No |
|---|---|---|---|
| 10 | 30 | 10 | VC1FTK1AL010-90-F |
| 16 | 40 | 16 | VC1FTK1AL016-90-F |
| 25 | 50 | 24 | VC1FTK1AL025-90-F |
| 40 | 65 | 40.5 | VC1FTK1AL040-90-F |
| Size (DN) | A (mm) | B (mm) |
|---|---|---|
| 10 | 30 | 10 |
| 16 | 40 | 16 |
| 25 | 50 | 24 |
| 40 | 65 | 40.5 |
