The ISO-KF Flange With Pipe Thread Male is designed for ISO-KF vacuum systems where a male pipe thread connection is required for reliable integration of instrumentation, fittings, or auxiliary line connections. Based on the product sheet image, it is available in Stainless Steel 304 / 1.4301 and Stainless Steel 316L / 1.4404, with standard configurations from DN10 to DN50 and a range of male pipe thread options.
| Field | Data |
|---|---|
| Product Name | ISO-KF Flange With Pipe Thread Male |
| System | ISO-KF |
| Product Type | Flange With Pipe Thread Male |
| Connection Type | Male pipe thread |
| Material Versions | Stainless Steel 304 / 1.4301, Stainless Steel 316L / 1.4404 |
| Available Sizes (DN) | 10, 16, 25, 40, 50 |
| Available Thread Options | G3/8, G1/4, G1/2, G3/4, G1, G1.25, G1.5, G2 |
| Main Dimensions | A, B, L, Thread |
| Temperature Range - Stainless Steel 304 / 1.4301 | -196 to 300 °C |
| Temperature Range - Stainless Steel 316L / 1.4404 | -196 to 350 °C |
| Size (DN) | A (mm) | B (mm) | L (mm) | Thread | Order No |
|---|---|---|---|---|---|
| 10 | 12 | 10 | 30 | G3/8 | VC1ADC1SS010-04-30 |
| 16 | 9 | 9 | 30 | G1/4 | VC1ADC1SS016-03-30 |
| 16 | 12 | 16 | 30 | G1/2 | VC1ADC1SS016-05-30 |
| 16 | 12 | 16 | 30 | G3/8 | VC1ADC1SS016-04-30 |
| 25 | 12 | 16 | 30 | G1/2 | VC1ADC1SS025-05-30 |
| 25 | 12 | 20 | 30 | G3/4 | VC1ADC1SS025-07-30 |
| 25 | 12 | 24 | 30 | G1 | VC1ADC1SS025-09-30 |
| 40 | 14 | 35 | 30 | G1.25 | VC1ADC1SS040-11-30 |
| 40 | 12 | 41 | 30 | G1.5 | VC1ADC1SS040-13-30 |
| 50 | 16 | 51 | 35 | G2 | VC1ADC1SS050-15-35 |
| Size (DN) | A (mm) | B (mm) | L (mm) | Thread | Order No |
|---|---|---|---|---|---|
| 10 | 12 | 10 | 30 | G3/8 | VC1ADC2SS010-04-30 |
| 16 | 9 | 9 | 30 | G1/4 | VC1ADC2SS016-03-30 |
| 16 | 12 | 16 | 30 | G1/2 | VC1ADC2SS016-05-30 |
| 16 | 12 | 16 | 30 | G3/8 | VC1ADC2SS016-04-30 |
| 25 | 12 | 16 | 30 | G1/2 | VC1ADC2SS025-05-30 |
| 25 | 12 | 20 | 30 | G3/4 | VC1ADC2SS025-07-30 |
| 25 | 12 | 24 | 30 | G1 | VC1ADC2SS025-09-30 |
| 40 | 14 | 35 | 30 | G1.25 | VC1ADC2SS040-11-30 |
| 40 | 12 | 41 | 30 | G1.5 | VC1ADC2SS040-13-30 |
| 50 | 16 | 51 | 35 | G2 | VC1ADC2SS050-15-35 |
| Size (DN) | A (mm) | B (mm) | L (mm) | Thread |
|---|---|---|---|---|
| 10 | 12 | 10 | 30 | G3/8 |
| 16 | 9 | 9 | 30 | G1/4 |
| 16 | 12 | 16 | 30 | G1/2 |
| 16 | 12 | 16 | 30 | G3/8 |
| 25 | 12 | 16 | 30 | G1/2 |
| 25 | 12 | 20 | 30 | G3/4 |
| 25 | 12 | 24 | 30 | G1 |
| 40 | 14 | 35 | 30 | G1.25 |
| 40 | 12 | 41 | 30 | G1.5 |
| 50 | 16 | 51 | 35 | G2 |
| Size (DN) | A (mm) | B (mm) | L (mm) | Thread |
|---|---|---|---|---|
| 10 | 12 | 10 | 30 | G3/8 |
| 16 | 9 | 9 | 30 | G1/4 |
| 16 | 12 | 16 | 30 | G1/2 |
| 16 | 12 | 16 | 30 | G3/8 |
| 25 | 12 | 16 | 30 | G1/2 |
| 25 | 12 | 20 | 30 | G3/4 |
| 25 | 12 | 24 | 30 | G1 |
| 40 | 14 | 35 | 30 | G1.25 |
| 40 | 12 | 41 | 30 | G1.5 |
| 50 | 16 | 51 | 35 | G2 |
